The EQUUS 175N UN is a version with dual winch (2x10t - 2x16t), hydraulic crane EQUUS 120/75 with an inserted gripper as standard in size 0.35 and with the option of using a clamping bank with automatic locking (holding pressure) of the gripping tongs. The gripper is available in a version with a saw. The hydraulic arms have the lengths 7.5 m, 8.2 m and 9.5 m (double telescope). These are the best-selling designs, suitable for most common jobs that require high performance in a short period of time. The forest tractor has a weight from approx. 12 600 kg.
The main attributes of the EQUUS 175N UN are robustness, economy and reliability. An easy-to-use machine that meets today's demanding criteria, equipped with a state-of-the-art hydrostat with perfectly controlled cooling, allows the combination of a high-performance forest machine with the ability to drive on roads at speeds of 40 km / h up to a distance of more than 100 km! The lowest center of gravity in the class in question predestines it for work in the most difficult terrain.
As one of the first forestry skidder manufacturers, EQUUS has installed the most advanced CUMMINS B45 engine that meets the requirements of the most demanding STAGE V emission class. With the power of 175 hp and the torque of 780 Nm, this direct-injection 4-cylinder engine delivers a performance comparable to larger and more expensive 6-cylinder engines, while being lighter, safer and more environmentally friendly.
Type: CUMMINS B45
Power: 129 kW @ 2200 rpm – 780 Nm @ 1500 rpm Stage V. At the moment the highest environmental standards and with certificates from producer of combustion engine.
Specifications: diesel, 4-stroke with direct fuel injection (Electronic Common Rail)
Nr.of cylinders: 4
Volume of cylinders: 4,5L
Fuel cleaning: water separator, fuel filter
Lubrication: pressurized, circulating with wet oil pan and oil filter
Cooling: coolant circulation through the water pump, termoregulator's valve
Placed: in connection with hydrogenerators
Handling: pedal with potentiometer
